End Caps

Fernco EPDM End Caps are ideal for capping pipe ends, cleanouts and open test pipes. Suitable for both above and below ground applications, Fernco end caps can be used on any pipe material.

  • Quick and easy to install
  • Remove and reuse as required
  • Ideal for capping drainage pipes off to conduct air and watertight tests
  • Wide range of sizes

    SKU: end-caps Category:

    Introduction to End Caps

    Fernco End Caps, made from EPDM and stainless steel, are ideal for capping pipe ends, cleanouts and open test pipes. Suitable for both above and below ground applications, Fernco end caps can be used on any pipe material. The convex face allows the cap to withstand greater pressure for testing purposes and minimises ballooning.

    Air & Water Testing

    Fernco End Caps are ideal to be used for both air and water testing of drainage pipelines.

    The pressures used during testing are usually very low and as a result the end cap is able to resist this pressure without ballooning excessively.

    However it is important to brace the end cap to minimise the inflation and to prevent the end cap sliding off the end of the pipe which is possible with smooth walled pipes.

    The clamp is capable of sealing up to a pressure of 0.6bar. At this pressure, bracing should be used as a precautionary measure.
